Home » Products » CBN Tools » PCBN Insert » PCBN Insert

Grade	Grain Size(um)	CBN Content(%)	Applications
MRN350 Solid CBN	20um	90%	For machining of cast iron and hard cast irons and heavy interrupted machining of hardened steels; such as brake discs, pump bodies and impellers and large rolls.
MRN950 Solid CBN	5um	65%	General use in continuous and light interrupted machining of hardened steel.
MRK850	2um	85%	For applications such as grey iron fine boring and valve seat machining, due to excellent strength and abrasion resistance. Ideal for heavily interrupted cutting of all hard and abrasive work piece materials, including powder metallurgy components. Proven performance also in hard fine milling applications.
MRK900	4um	90%	Ideal for applications where longer tool life is required. Excels in interrupted machining of grey and hard cast irons, hardened steel milling and in the machining of the majority of valve seat ring alloys. Excellent first choice grade for the majority of ferrous powder metals.
MRK650	3um	65%	For moderately to heavily interrupted turning of all common hardened steels. Provides an excellent balance of toughness. Also used for plunge machining of valve seat rings.
MRK450	1.5um	45%	For moderately interrupted hard turning and finish hard milling as well as high speed continuous turning.
MRK500	1.5um	50%	For continuously and lightly interrupted cutting of the majority of automotive steels. Excellent abrasion resistance makes it the ideal choice for cold work tool steels and certain valve seat alloys. Also recommended for finishing abrasive high strength cast irons.

PCBN Inserts	ISO Item Number	IC	S	R	D1	Edge Prep.
CCGW	CCGW060202-2	6.35	2.38	0.2	2.8	S01020 S01525 S02020 S02025
	CCGW060204-2	6.35	2.38	0.4	2.8
	CCGW060208-2	6.35	2.38	0.8	2.8
	CCGW09T302-2	9.525	3.97	0.2	4.4
	CCGW09T304-2	9.525	3.97	0.4	4.4
	CCGW09T308-2	9.525	3.97	0.8	4.4
CNGA	CNGA120404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	CNGA120408-2	12.7	4.76	0.8	5.16
	CNGA120412-2	12.7	4.76	1.2	5.16



DCGW	DCGW070202-2	6.35	2.38	0.2	2.8	S01020 S01525 S02020 S02025
	DCGW070204-2	6.35	2.38	0.4	2.8
	DCGW070208-2	6.35	2.38	0.8	2.8
	DCGW11T302-2	9.525	3.97	0.2	4.4
	DCGW11T304-2	9.525	3.97	0.4	4.4
	DCGW11T308-2	9.525	3.97	0.8	4.4
DNGA	DNGA150404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	DNGA150408-2	12.7	4.76	0.8	5.16
	DNGA150412-2	12.7	4.76	1.2	5.16
	DNGA150604-2	12.7	6.35	0.4	5.16
	DNGA150608-2	12.7	6.35	0.5	5.16
	DNGA150612-2	12.7	6.35	1.2	5.16
SNGA	SNGA120404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	SNGA120408-2	12.7	4.76	0.8	5.16
	SNGA120412-2	12.7	4.76	1.2	5.16



SCGW	SCGW09T304-2	9.525	3.97	0..4	4.4	S01020 S01525 S02020 S02025
	SCGW09T308-2	9.525	3.97	0.8	4.4
					-
					-


SPGW	SPGW09T304-2	9.525	3.97	0.4	4.4	S01020 S01525 S02020 S02025
	SPGW09T308-2	9.525	3.97	0.8	4.4




TNGA	TNGA160404-3	9.525	4.76	0.4	3.81	S01020 S01525 S02020 S02025
	TNGA160408-3	9.525	4.76	0.8	3.81
	TNGA160412-3	9.525	4.76	1.2	3.81



TCGW	TCGW090202-3	5.56	2.38	0.2	2.5	S01020 S01525 S02020 S02025
	TCGW090204-3	5.56	2.38	0.4	2.5
	TCGW090208-3	5.56	2.38	0.8	2.5
	TCGW110202-3	6.35	2.38	0.2	2.8
	TCGW110204-3	6.35	2.38	0.4	2.8
	TCGW110208-3	6.35	2.38	0.8	2.8
TPGB	TPGB110304-3	6.35	3.18	0.4	3.3	S01020 S01525 S02020 S02025
	TPGB110308-3	6.35	3.18	0.4	3.3




TPGW	TPGW090204	5.56	2.38	0.4	2.5	S01020 S01525 S02020 S02025
	TPGW090208	5.56	2.38	0.8	2.5
	TPGW110204	6.35	2.38	0.4	2.8
	TPGW110208	6.35	2.38	0.8	2.8


VNGA						S01020 S01525 S02020 S02025

	VNGA160404-4	9.525	4.76	0.4	3.81
	VNGA160408-4	9.525	4.76	0.8	3.81
	VNGA160412-4	9.525	4.76	1.2	3.81

WNGA						S01020 S01525 S02020 S02025

	WNGA080404-6	12.7	4.76	0.4	5.13
	WNGA080408-6	12.7	4.76	0.8	5.13
	WNGA080412-6	12.7	4.76	1.2	5.13

Grade	Grain Size(um)	CBN Content(%)	Applications
MRN350 Solid CBN	20um	90%	For machining of cast iron and hard cast irons and heavy interrupted machining of hardened steels; such as brake discs, pump bodies and impellers and large rolls.
MRN950 Solid CBN	5um	65%	General use in continuous and light interrupted machining of hardened steel.
MRK850	2um	85%	For applications such as grey iron fine boring and valve seat machining, due to excellent strength and abrasion resistance. Ideal for heavily interrupted cutting of all hard and abrasive work piece materials, including powder metallurgy components. Proven performance also in hard fine milling applications.
MRK900	4um	90%	Ideal for applications where longer tool life is required. Excels in interrupted machining of grey and hard cast irons, hardened steel milling and in the machining of the majority of valve seat ring alloys. Excellent first choice grade for the majority of ferrous powder metals.
MRK650	3um	65%	For moderately to heavily interrupted turning of all common hardened steels. Provides an excellent balance of toughness. Also used for plunge machining of valve seat rings.
MRK450	1.5um	45%	For moderately interrupted hard turning and finish hard milling as well as high speed continuous turning.
MRK500	1.5um	50%	For continuously and lightly interrupted cutting of the majority of automotive steels. Excellent abrasion resistance makes it the ideal choice for cold work tool steels and certain valve seat alloys. Also recommended for finishing abrasive high strength cast irons.

PCBN Inserts	ISO Item Number	IC	S	R	D1	Edge Prep.
CCGW	CCGW060202-2	6.35	2.38	0.2	2.8	S01020 S01525 S02020 S02025
	CCGW060204-2	6.35	2.38	0.4	2.8
	CCGW060208-2	6.35	2.38	0.8	2.8
	CCGW09T302-2	9.525	3.97	0.2	4.4
	CCGW09T304-2	9.525	3.97	0.4	4.4
	CCGW09T308-2	9.525	3.97	0.8	4.4
CNGA	CNGA120404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	CNGA120408-2	12.7	4.76	0.8	5.16
	CNGA120412-2	12.7	4.76	1.2	5.16



DCGW	DCGW070202-2	6.35	2.38	0.2	2.8	S01020 S01525 S02020 S02025
	DCGW070204-2	6.35	2.38	0.4	2.8
	DCGW070208-2	6.35	2.38	0.8	2.8
	DCGW11T302-2	9.525	3.97	0.2	4.4
	DCGW11T304-2	9.525	3.97	0.4	4.4
	DCGW11T308-2	9.525	3.97	0.8	4.4
DNGA	DNGA150404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	DNGA150408-2	12.7	4.76	0.8	5.16
	DNGA150412-2	12.7	4.76	1.2	5.16
	DNGA150604-2	12.7	6.35	0.4	5.16
	DNGA150608-2	12.7	6.35	0.5	5.16
	DNGA150612-2	12.7	6.35	1.2	5.16
SNGA	SNGA120404-2	12.7	4.76	0.4	5.16	S01020 S01525 S02020 S02025
	SNGA120408-2	12.7	4.76	0.8	5.16
	SNGA120412-2	12.7	4.76	1.2	5.16



SCGW	SCGW09T304-2	9.525	3.97	0..4	4.4	S01020 S01525 S02020 S02025
	SCGW09T308-2	9.525	3.97	0.8	4.4
					-
					-


SPGW	SPGW09T304-2	9.525	3.97	0.4	4.4	S01020 S01525 S02020 S02025
	SPGW09T308-2	9.525	3.97	0.8	4.4




TNGA	TNGA160404-3	9.525	4.76	0.4	3.81	S01020 S01525 S02020 S02025
	TNGA160408-3	9.525	4.76	0.8	3.81
	TNGA160412-3	9.525	4.76	1.2	3.81



TCGW	TCGW090202-3	5.56	2.38	0.2	2.5	S01020 S01525 S02020 S02025
	TCGW090204-3	5.56	2.38	0.4	2.5
	TCGW090208-3	5.56	2.38	0.8	2.5
	TCGW110202-3	6.35	2.38	0.2	2.8
	TCGW110204-3	6.35	2.38	0.4	2.8
	TCGW110208-3	6.35	2.38	0.8	2.8
TPGB	TPGB110304-3	6.35	3.18	0.4	3.3	S01020 S01525 S02020 S02025
	TPGB110308-3	6.35	3.18	0.4	3.3




TPGW	TPGW090204	5.56	2.38	0.4	2.5	S01020 S01525 S02020 S02025
	TPGW090208	5.56	2.38	0.8	2.5
	TPGW110204	6.35	2.38	0.4	2.8
	TPGW110208	6.35	2.38	0.8	2.8


VNGA						S01020 S01525 S02020 S02025

	VNGA160404-4	9.525	4.76	0.4	3.81
	VNGA160408-4	9.525	4.76	0.8	3.81
	VNGA160412-4	9.525	4.76	1.2	3.81

WNGA						S01020 S01525 S02020 S02025

	WNGA080404-6	12.7	4.76	0.4	5.13
	WNGA080408-6	12.7	4.76	0.8	5.13
	WNGA080412-6	12.7	4.76	1.2	5.13
